Mercury Tower 3000VA
Share :
This high frequency online double conversion UPS features full digital control and a compact design for a smaller footprint. It operates across wide input voltage and frequency windows with a 0.9 power factor.
The UPS includes self-testing on startup, cold start, auto restart, and a maintenance bypass switch. It also features RS232, USB, and EPO communication interfaces, with SNMP available as an optional feature.
Intelligent fan speed regulation and multiple protection functions provide comprehensive system monitoring, including short-circuit, overload, overheat, battery overcharge and overdischarge, output low voltage, and fan fault alarm.
Features:
High frequency online double conversion
Full digital control
Compact design with a smaller footprint
Wide input voltage and frequency windows
0.9 power factor
Self-testing on UPS startup
RS232 / USB / EPO communication interfaces
Optional SNMP support
Cold start and auto restart
Maintenance bypass switch
Intelligent fan speed regulation
Multiple protection functions
Suitable for electronic, non-inductive loads
12-month warranty
General
- Phase:Single Phase
- Capacity (VA / Watts):2000VA / 1800W
Input
- Nominal Voltage:208 / 220 / 230 / 240 VAC
- Operating Voltage Range:see below
- Low Line Transfer:176Vac ± 5% @ 100% - 50% load; 110Vac ± 5% @ 50% - 0% load;
- Low Line Comeback:186Vac ± 5% @ 100% - 50% load; 120Vac ± 5% @ 50% - 0% load;
- High Line Transfer:264Vac ± 5% @ 100% - 50% load; 300Vac ± 5% @ 50% - 0% load;
- High Line Comeback:254Vac ± 5% @ 100% - 50% load; 290Vac ± 5% @ 50% - 0% load;
- Operating Frequency Range **:40 - 70Hz
- Power Factor:0.99 @ 100% load (Nominal Input Voltage)
- Bypass Voltage Range:see below
- Bypass High Voltage Point:230 - 264: Setting the high voltage point in LCD from 230Vac to 264Vac (Default: 264Vac)
- Bypass Low Voltage Point:176 - 220: Setting the low voltage point in LCD from 176Vac to 220Vac (Default: 176Vac)
- Generator Output:Support
Output
- Output Voltage *:200*208 / 220 / 230 / 240Vac
- Power Factor:0.9
- Voltage regulation:8±1%
- Frequency:See Below
- Line Mode (Synchronized range):46-54Hz or 56-64Hz
- Battery Mode:(50 / 60 0.1)Hz ±
- Crest Factor:3 : 1
- Harmonic Distortion (THDv):≤3% THD (Linear load) ≤5% THD (None-Linear load)
- Waveform:Pure Sinewave
- Transfer Time:See Below
- AC Mode ↔ Battery Mode:Zero
- Inverter ↔ Bypass:4ms (Typical)
- Efficiency:90% (AC Mode) 87% (DC Mode)
System Features
- Overload:See Below
- Line Mode:105%-125%:UPS transfer to bypass after 1min when utility normal | 125%-130%:UPS transfer to bypass after 30sec when utility normal | >130%:UPS transfer to bypass immediately when utility normal
- Battery Mode:105% - 125%: UPS after 1minute shut down | 125% - 130%: UPS after 10 seconds shut down | >130%: UPS immediately shut down
- Short Circuit Protection:Available
- Overheat:Line mode: Switch to bypass; Backup mode: Shut down UPS immediately
- Low Battery Voltage:Alarm and switch off
- EPO (Optional):Shut down UPS immediately
- Audible & Visual Alarms:Line Failure; Battery Low; Overload; System Fault
- Communication Interface:USB (or RS232 SNMP card (optional)
Environment
- Operating Temperature:0°C ∼ 40 °C
- Storage Temperature:-25°C ∼ 55°C
- Humidity:20∼90% RH @ 0∼40°C (Non-condensing)
- Altitude:< 1500m
- Noise Level:Less than 55dBA at 1 Meter
Physical
- Dimensions (WxDxH) mm:191 × 460 × 337
- Net Weight (kg):10.9
Standards
- Operating Temperature:IEC/EN62040-1 | IEC/EN62477-1
- EMC:IEC/EN62040-2 | IEC61000-4-2 | IEC61000-4-3 | IEC61000-4-4 | IEC61000-4-5 | IEC61000-4-6 | IEC61000-4-8
